EXARK XK – 650

EXARK XK – 650

The EXARK XK-650 is a robust, simple to use UHF passive RFID Handheld designed for all day intensive use. The handheld characteristics provides the flexibility to use your preferred operating system type/version while enabling access to the latest generation in communications infrastructure without being tied more slowly evolving monolithic device.

Description

  • Supports Google Android® via Smart Device
  • Enables LTE and 11ac/ad via Smart Device
  • ETSI 6–867.6 MHz or FCC/IC 902–928 MHz
  • 2D imager supporting all major 1D / 2D barcodes
  • Ergonomic 320 g / 3 oz
  • Robust Quadlock™ physical smart device Connection
  • Bluetooth Low Energy communications to Smart Device
  • Camera with Flash | GPS
  • Memory 2 GB RAM / 16 GB ROM
  • Fast RFID tag capture in various environments
  • High performance battery for full shift operation

Product Details

ELECTRICAL:



Standards: ISO 18000-63 (EPC Class 1 Gen2v2) AES authentication in accordance with ISO/IEC 29167-10 supported
Frequency: ETSI 865.6–867.6 MHz or FCC/IC 902–928 MHz
RF Power: ERP 2W/EIRP 3.3W
Power: Li-ion, rechargeable, 8000mAh – Standby: over 500 hours , Continuous use: over 12 hours



MECHANICAL:



Antenna features: Software controlled antenna modes :circular and proximity Nominal reading distance: circular polarization mode 18m/59 ft, proximity mode, read range down to 1 cm/0.4 inch Double -capacity single battery 8000 mAh
Dimensions: 164.2 x 80.0 x 24.3mm / 6.46 x 3.15 x 0.96in
Weight: 654g / 23.07oz
Display: 5.2” IPS FHD 1920×1080
Touch Panel: Gorilla Glass, multi -touch panel



ENVIRONMENT:



Operating Temp.: -4 F to 122F / -20 C to 50 C
Storage Temp.: -40 F to 158 F / -40 C to 70 C
Humidity: 5%RH – 95%RH non condensing



APPLICATION INTERFACE:



Host API: LLRP API or REST API
